Huawei WiFi WS5200 Guida Rapida

Tipo
Guida Rapida
HUAWEI WiFi WS5200
Quick Start Guide
96727049_01
Contents
Quick Start Guide
.........................................................................
1
Guide de démarrage rapide
........................................................
14
Kurzanleitung
..............................................................................
28
Guida di avvio rapido
..................................................................
42
Snelstartgids
...............................................................................
56
Guia de início rápido
...................................................................
70
Guía de inicio rápido
...................................................................
84
1
Quick Start Guide
Step 1: Connecting the cables
If the indicator stays red, this indicates that the router is not connected to the Internet.
Please refer to "Step 2: Conguring the network settings".
HUAWEI WiFi WS5200
Optical/broadband/cable modem
Internet
Position the four antennas
upright to ensure optimal
Wi-Fi
®
signal strength.
from your broadband provider
WAN
POWER WAN LAN1 LAN2 LAN3
RESET
RESET
LAN
PON
POWER
LAN
2
Connect your mobile phone or computer to the
new router's Wi-Fi network (no password required).
Check the Wi-Fi name on the bottom of the new
router.
Open the browser, you will be automatically
redirected.
(If the page is not displayed automatically,
enter 192.168.3.1 in the address bar.) .
WiFi
WiFi
Connected
Welcome to
HUAWEI WiFi WS5200
Touch
XXXXXX
Step 2: Conguring the network settings
1
2
Let's Start
Wi-Fi Name: XXXXXX
3
3
If your Internet
connection does not
require an account and
password:
Please skip to the
next step.
If you remember your
broadband account
and password:
Enter your broadband
account and password.
Broadband account
Broadband password
Old router's WAN port
LAN port
If you have forgotten your broadband account and password,
obtain the broadband account and password from the old router.
Take another Ethernet cable and connect the WAN port of the old
router to the LAN port of the new router.
Or contact your Internet service provider to obtain a broadband
account and password.
Internet access wizard Internet access wizard Internet access wizard
Next
Retrieve
Next
Back
Retrieve
Back
If you need to congure VLAN on your network, contact your broadband carrier to conrm the VLAN
parameters, and enable the VLAN switch on the screen.
Touch
Internet access wizard
Broadband account
Broadband password
Next
Retrieve
VLAN
VLAN
4
Set a new Wi-Fi name, Wi-Fi password, and admin password for the new router.
You can use the Wi-Fi password as the router admin password.
4
Enable
Prioritize 5 GHz
: The 2.4 GHz and 5 GHz Wi-Fi names are the same.
Priority usage of 5 GHz Wi-Fi band over 2.4 GHz band when signal strength is equal to
increase connection speeds.
Conguration
complete
Connect to the new
Wi-Fi network to surf
the Internet
Internet access wizard
Prioritize 5 GHz
Wi-Fi network name
Wi-Fi network password
NEXT
Use Wi-Fi password as
the router admin password
Touch
Internet access wizard
5
Indicator
Indicator
If you touch the
H
button accidentally, wait for approximately two
minutes and the indicator will be reset automatically.
The
H
button also features WPS functionality.
Steady green
Steady red
Flashing
Connected to the Internet.
Not connected to the Internet.
The router has detected a pairable device.
Loose cable or connect error. Check the cable.
Broadband network error. Contact your Internet service provider.
When other HUAWEI routers (with
H
or
Hi
button) are detected, the indicator
will ash. When this happens, press the router's
H
button. The indicator
should ash quickly, indicating that the pairable device is connecting to the
router's Wi-Fi. The connection process is complete when the indicator stops
ashing.
6
Manage the router with our mobile app
Scan the QR code to download and install the HUAWEI smart device
management app on your mobile phone or tablet. You can use the app
to manage your router.
7
Frequently Asked Questions (FAQs)
1. What should I do if I encounter any of the following issues when conguring the router?
If your device did not detect the router's Wi-Fi: Ensure that the router is powered on. Wait for a moment (until the router is started)
and try to search again on your device.
If you cannot visit the router's web-based conguration page on your device: Ensure that your device is connected to the router's
Wi-Fi network, and then enter 192.168.3.1 in the browser address bar to visit this page on your device.
If the page displays "
Cable disconnected
": Ensure that the router's WAN port is connected to the modem's LAN port, and the
modem has Internet access. Check that all contact points are securely connected and in good contact, and the network cables are
in good condition.
If the page displays "
Account or password error
": Please enter your broadband account and password again. If the issue
persists, your broadband provider may have bound the MAC address of your old router, causing your new router to be unable to
connect. To x this issue, select
Retrieve
and follow the onscreen instructions. Alternatively, contact your Internet service provider
for assistance.
If the page displays "
Failed to retrieve network settings from old router
": Ensure that the router is connected to a power source,
and that the old router's WAN port is already connected to the new router's LAN port. Restart your old router and then touch
Try
again
.
If the issue persists, restore the router to the factory settings, and follow the guide to reconnect the cables and congure the router.
8
2. What should I do if I forget my login password for the app or the router's web-based management page?
4. How do I pair a Wi-Fi device with my HUAWEI WiFi WS5200 using WPS?
3. How do I restore the HUAWEI WiFi WS5200 to its factory settings?
Try using the router's Wi-Fi password to log in. If the issue persists, restore the router to its factory settings.
When your HUAWEI WiFi WS5200 is powered on, press its H button, and then press the WPS button on the Wi-Fi device (such as
a phone) within two minutes to initiate standard WPS negotiation and incorporate the Wi-Fi devices into the router's Wi-Fi network.
Connect the router to the power supply and wait until the router completes the startup process. Use a needle or pin to press the
RESET
button on the router for more than two seconds until the indicator light goes out. Wait for the router to complete the restart
process. When the indicator turns red, this indicates that the router has been restored to its factory settings.
All settings will be cleared if the router is restored to its factory settings. You will need to re-congure the router.
9
5. Does the HUAWEI WiFi WS5200 support 5 GHz Wi-Fi?
How do I connect to the router's 5 GHz Wi-Fi?
5 GHz Wi-Fi is supported.
The Wi-Fi names for 2.4 GHz and 5 GHz are the same by default. You will be automatically connected to the faster Wi-Fi network.
If you want to use 5 GHz Wi-Fi only, you can disable the Prioritize 5 GHz feature by performing the following steps:
1) Connect your phone to the router's Wi-Fi network.
2) Enter 192.168.3.1 in your browser address bar and follow the onscreen instructions to log in.
3) Select
My Wi-Fi
and disable
Prioritize 5 GHz
.
You will now be able to nd two Wi-Fi network names. Connect to the Wi-Fi network with "_5G" at the end of its name.
10
Safety Information
Copyright © Huawei Technologies Co., Ltd. 2020. All rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT CONSTITUTE ANY KIND OF WARRANTIES.
Trademarks and Permissions
, , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.
Wi-Fi
®
, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are trademarks of Wi-Fi Alliance.
Other trademarks, product, service and company names mentioned may be the property of their respective owners.
Version Update
In order to improve the security of the product and provide you with a better user experience, we will push version update information to you on a
regular basis when an important update is released.
Privacy Policy
To better understand how we use and protect your personal information, please read the privacy policy at http://consumer.huawei.com/privacy-policy.
End User License Agreement
Please read and agree to the End User License Agreement (HUAWEI EULA) on the product’s management page before using the product.
Safety Information
Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic
devices.
Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential
11
interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your
front pocket.
Avoid dusty, damp, or dirty environments. Avoid magnetic elds. Using the device in these environments may result in circuit malfunctions.
Ideal operating temperatures are 0°C to 40°C. Ideal storage temperatures are -40°C to +70°C. Extreme heat or cold may damage your device or
accessories.
Keep the device and accessories in a well-ventilated and cool area away from direct sunlight. Do not enclose or cover your device with towels or
other objects. Do not place the device in a container with poor heat dissipation, such as a box or bag.
The device should be installed and operated with a minimum distance of 20 cm between the radiator and your body.
Using an unapproved or incompatible power adapter, charger or battery may cause re, explosion or other hazards.
For pluggable devices, the socket-outlet shall be installed near the devices and shall be easily accessible.
Unplug the power adapter from electrical outlets and the device when not in use.
Do not touch the device or the power adapter with wet hands. Doing so may lead to short circuits, malfunctions, or electric shocks.
Disposal and recycling information
The crossed-out wheeled-bin symbol on your product, battery, literature or packaging reminds you that all electronic products and batteries
must be taken to separate waste collection points at the end of their working lives; they must not be disposed of in the normal waste stream
with household garbage. It is the responsibility of the user to dispose of the equipment using a designated collection point or service for
separate recycling of waste electrical and electronic equipment (WEEE) and batteries according to local laws.
Proper collection and recycling of your equipment helps ensure electrical and electronic equipment (EEE) waste is recycled in a manner that
conserves valuable materials and protects human health and the environment, improper handling, accidental breakage, damage, and/or improper
recycling at the end of its life may be harmful for health and environment. For more information about where and how to drop o your EEE waste,
12
please contact your local authorities, retailer or household waste disposal service or visit the website http://consumer.huawei.com/en/.
Reduction of hazardous substances
This device and any electrical accessories are compliant with local applicable rules on the restriction of the use of certain hazardous substances in
electrical and electronic equipment, such as EU REACH, RoHS and Batteries (where included) regulations, etc. For declarations of conformity about
REACH and RoHS, please visit our web site http://consumer.huawei.com/certication.
EU regulatory conformance
Statement
Hereby, Huawei Technologies Co., Ltd. declares that this device WS5200 V2 is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
The most recent and valid version of the DoC (Declaration of Conformity) can be viewed at http://consumer.huawei.com/certication.
This device may be operated in all member states of the EU.
Observe national and local regulations where the device is used.
This device may be restricted for use, depending on the local network.
Restrictions in the 2.4 GHz band:
Norway:
This subsection does not apply for the geographical area within a radius of 20 km from the centre of Ny-Ålesund.
Restrictions in the 5 GHz band:
The 5150 to 5350 MHz frequency range is restricted to indoor use in: AT, BE, BG, CH, CY, CZ, DE, DK, EE, EL, ES, FI, FR, HR, HU, IE, IS, IT, LI, LT,
LU, LV, MT, NL, NO, PL, PT, RO, SE, SI, SK, TR, UK(NI).
In accordance with the relevant statutory requirements in the UK, the 5150 to 5350 MHz frequency range is restricted to indoor use in the United
Kingdom.
13
Frequency bands and power
(a) Frequency bands in which the radio equipment operates: Some bands may not be available in all countries or all areas. Please contact the local
carrier for more details.
(b) Maximum radio-frequency power transmitted in the frequency bands in which the radio equipment operates: The maximum power for all bands is
less than the highest limit value specied in the related Harmonized Standard.
The frequency bands and transmitting power (radiated and/or conducted) nominal limits applicable to this radio equipment are as follows:
Wi-Fi 2.4G: 20 dBm, Wi-Fi 5G: 5150-5350 MHz: 23 dBm, 5470-5725 MHz: 30dBm.
Accessories and Software Information
It is recommended that the following accessories should be used:
Adapters: HW-120100X01 (X represents the dierent plug types used, which can be either A, B, C, E, I, J, K, R, U or Z, depending on your region).
The product software version is 10.0.2.2. Software updates will be released by the manufacturer to x bugs or enhance functions after the product
has been released. All software versions released by the manufacturer have been veried and are still compliant with the related rules.
All RF parameters (for example, frequency range and output power) are not accessible to the user, and cannot be changed by the user.
For the most recent information about accessories and software, please see the DoC (Declaration of Conrmation) at
http://consumer.huawei.com/certication.
ErP Product Information
Huawei Technologies Co., Ltd. hereby declares that its products conform to the Energy-related Products Directive (ErP) 2009/125/EC.
For detailed ErP information and the user manuals required by Commission Regulation, please visit: http://consumer.huawei.com/en/certication.
Please visit http://consumer.huawei.com/en/support/hotline for recently updated hotline and email address in your country or region.
14
Guide de démarrage rapide
Étape 1 : Brancher les câbles
Si le voyant reste rouge, cela signie que le routeur n'est pas connecté à Internet.
Veuillez vous référer à "Étape 2 : Congurer les paramètres réseau".
HUAWEI WiFi WS5200
Modem Optique/Haut débit/Câble
Internet
Placez les quatre antennes
à la verticale pour garantir
un signal Wi-Fi
®
optimal.
de votre fournisseur
d'accès haut débit
WAN
POWER WAN LAN1 LAN2 LAN3
RESET
RESET
LAN
PON
POWER
LAN
15
Connectez votre téléphone portable ou votre
ordinateur au réseau Wi-Fi du nouveau routeur
(pas de mot de passe requis).
Vériez le nom du Wi-Fi (Wi-Fi Name) indiqué
sur la partie inférieure du nouveau routeur.
Ouvrez le navigateur, vous serez
automatiquement redirigé.
(Si la page ne s'ache pas automatiquement,
saisir 192.168.3.1).
Wi-Fi
Wi-Fi
Connecté
Bienvenue chez
HUAWEI WiFi WS5200
Touchez
XXXXXX
Étape 2 : Congurer les paramètres réseau
1
2
Commençons
Wi-Fi Name: XXXXXX
16
3
Si votre connexion
Internet n'exige aucun
identiant ni mot de
passe :
passez à l'étape
suivante.
Si vous connaissez les
références de votre compte
haut débit:
saisissez l'identiant et le
mot de passe du compte
haut débit.
Compte haut débit
Mot de passe du haut
débit
Port WAN de l'ancien
routeur
Port LAN
Si vous ne connaissez pas les références de votre compte haut
débit, vous pouvez récupérer l'identiant et le mot de passe
depuis l'ancien routeur. Prenez un autre câble Ethernet et
connectez le port WAN de l'ancien routeur avec le port LAN du
nouveau routeur.
Ou bien contactez votre fournisseur d'accès pour obtenir un
identiant et un mot de passe de compte haut débit.
Assistant d'accès
à Internet
Assistant d'accès
à Internet
Assistant d'accès
à Internet
Touchez
Assistant d'accès
à Internet
Compte haut débit
Mot de passe du haut
débit
Suivant
Récupérer
Suivant
Récupérer
Suivant
Retour
Récupérer
Retour
Si vous devez congurer le réseau local virtuel (VLAN) sur votre réseau, contactez votre opérateur
haut débit pour conrmer les paramètres du réseau local virtuel, puis activez le bouton VLAN à l'écran.
VLAN
VLAN
17
Dénissez un nouveau nom et mot de passe pour le réseau Wi-Fi, ainsi qu'un mot de passe
d'administrateur pour le nouveau routeur.
Vous pouvez utiliser le mot de passe du réseau Wi-Fi comme mot de passe d'administrateur du routeur.
4
Activer
Priorité au 5 GHz
: Les noms des réseaux Wi-Fi 2,4 GHz et 5 GHz sont identiques.
Le réseau Wi-Fi 5 GHz sera utilisé en priorité par rapport au réseau Wi-Fi 2.4 GHz quand la force du
signal est équivalente, permettant d'accroître les vitesses de connexion.
Conguration
terminée
Connectez-vous au
nouveau réseau Wi-Fi
pour naviguer sur Internet
Assistant d'accès
à Internet
Priorité au 5 GHz
Nom du réseau Wi-Fi
MDP réseau Wi-Fi
SUIVANT
Utiliser le mot de passe du
Wi-Fi comme mot de passe
administrateur du routeur
Touchez
Assistant d'accès
à Internet
18
Voyant
Voyant
Si vous touchez le bouton
H
par inadvertance, attendez environ deux
minutes. Le voyant se réinitialisera automatiquement.
Le bouton
H
prend également en charge la fonctionnalité WPS.
Vert continu
Rouge
continu
Clignotant
Connecté à Internet.
Non connecté à Internet.
Le routeur a détecté un appareil pouvant être lié.
Câble mal branché ou erreur de connexion. Vérier le câble.
Erreur du réseau haut débit. Contactez votre fournisseur d'accès haut débit.
Lorsque d'autres routeurs HUAWEI (comportant un bouton
H
ou
Hi
) sont
détectés, le voyant se met à clignoter. Lorsque cela se produit, appuyez sur le
bouton
H
du routeur. Le voyant doit alors se mettre à clignoter rapidement pour
indiquer que l'appareil associable est en train de se connecter au réseau Wi-Fi
du routeur. La connexion est établie lorsque le voyant s'arrête de clignoter.
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37
  • Page 38 38
  • Page 39 39
  • Page 40 40
  • Page 41 41
  • Page 42 42
  • Page 43 43
  • Page 44 44
  • Page 45 45
  • Page 46 46
  • Page 47 47
  • Page 48 48
  • Page 49 49
  • Page 50 50
  • Page 51 51
  • Page 52 52
  • Page 53 53
  • Page 54 54
  • Page 55 55
  • Page 56 56
  • Page 57 57
  • Page 58 58
  • Page 59 59
  • Page 60 60
  • Page 61 61
  • Page 62 62
  • Page 63 63
  • Page 64 64
  • Page 65 65
  • Page 66 66
  • Page 67 67
  • Page 68 68
  • Page 69 69
  • Page 70 70
  • Page 71 71
  • Page 72 72
  • Page 73 73
  • Page 74 74
  • Page 75 75
  • Page 76 76
  • Page 77 77
  • Page 78 78
  • Page 79 79
  • Page 80 80
  • Page 81 81
  • Page 82 82
  • Page 83 83
  • Page 84 84
  • Page 85 85
  • Page 86 86
  • Page 87 87
  • Page 88 88
  • Page 89 89
  • Page 90 90
  • Page 91 91
  • Page 92 92
  • Page 93 93
  • Page 94 94
  • Page 95 95
  • Page 96 96
  • Page 97 97
  • Page 98 98
  • Page 99 99
  • Page 100 100

Huawei WiFi WS5200 Guida Rapida

Tipo
Guida Rapida
